Item # bci2731888

Delta Tesla Monitor 17 Series Dual Function Pressure Balanced Shower Only with Integrated Volume Control - Less Rough-In Valve

Model: T17252-SS

Finish: Choose Finish
  • Brilliance Polished Nickel
    Brilliance Polished Nickel
    Special Order
  • Brilliance Stainless
    Brilliance Stainless
    12 In Stock
  • Chrome
    Special Order

Free Shipping!

12 In Stock

Product Overview

This product has additional required/recommended options. To configure, add to your cart.

Delta Tesla T17252 Shower Faucet Features:

  • Limited lifetime warranty for product and finish
  • Multi-function H2Okinetic shower head
  • Dual function cartridge - separate volume and temperature controls
  • Pressure balancing valve cartridge with scald guard
  • Hand shower pause button slows the water flow to a trickle for easy lathering and shaving
  • The Tesla Collection was inspired by the uniquely organic shapes found in nature
  • Shower Package Includes: valve trim, shower head, and shower arm
  • Spray settings include: H2OKinetic, Full Body, Pause
  • ADA compliant - complies with the standards set forth by the Americans with Disabilities Act for shower systems
  • Rough-in valve not included - when adding to cart, valve will be offered

Delta Tesla T17252 Shower Faucet Technologies / Benefits:

    • H2Okinetic: Delta's proprietary H2Okinetic technology uses the science of fluidics to create a warmer shower experience that feels like more water, without using more water. This is accomplished through larger water droplets that leave the spray head in a unique wave pattern. H2Okinetic showers are self-cleaning, have larger spray holes that don't clog, and do not use any moving parts, so they are very low-maintenance.
    • Monitor: Delta Monitor showers feature pressure balance valve cartridges, which protect against sudden temperature or pressure changes to keep the water in the shower within a safe +/- 3°F. Monitor valves also feature a high-temperature limit stop that can be adjusted to suit your shower needs.
    • MultiChoice Valve: Flexibility is the big benefit of the MultiChoice Universal Valve. Once the MultiChoice rough is installed, future shower function upgrades or style changes can easily be made without altering the plumbing behind the wall.
    • Independent Volume Control: Dual-control valve trims are what separate Delta showers from the competition. The top, smaller handle controls temperature, while the bottom, larger dial controls the water volume (flow rate). The distinct advantage to this is that you can set the temperature control to a temperature you like, and then leave it, turning the shower on and off each time with the volume control. You'll never have to fuss with the temperature again.

Delta Tesla T17252 Shower Faucet Specifications:

  • Valve Trim Dimensions: 7" W x 7" H
  • Temperature control includes pre-set safety stop with override
  • Temperature dial swings between 90° and 180°
  • Shower Head Dimensions: 7-5/8" W x 7-5/8"
  • Shower Head Height: 3-7/16"
  • Flow Rate: 1.75 GPM
  • Shower Head Spray Settings: full body spray, H2Okinetic spray, and pause control
  • Shower Arm Length: 7"

Delta Tesla T17252 Shower Faucet Variations:

  • T14252: This model with no volume control
  • T17T252: Thermostatic version of this model


This product is listed under the following manufacturer number(s):

Dimensions and Measurements

Flow Rate (GPM)
Shower Arm Reach
7 in.
Showerhead Flow Rate (GPM)
Showerhead Height
3.438 in.
Showerhead Width
7.625 in.
Valve Trim Height
7 in.
Valve Trim Width
7 in.

Included Components

Diverter Included
Handles Included
Handshower Included
Installation Hardware Included
Integrated Volume Control
Shower Head Included
Valve Included
Volume Control

Characteristics and Features

Faucet Type
Shower Faucet
Handle Material
Handle Style
Installation Type
Wall Mounted
Plastic, Metal
Number Of Handles
Pause Control
Scald Guard
Multi Function
Showerhead Shape
Spray Pattern
Pause, Massage, Full
Spray Settings
Valve Type
Pressure Balanced
Water Efficient

Manufacturer Technology

Delta Monitor
Delta Shower Series
17 Series
Delta Smart Solutions
Monitor Pressure Balance Valve, H2Okinetic Technology, MultiChoice Universal Valve
Delta Spray Pattern
Pause, H2Okinetic Spray, Full Body Spray
Valve Technology
Delta Monitor, Delta MultiChoice

Warranty and Product Information

Approved for Commercial Use
CA Drought Compliant
Manufacturer Warranty
Limited Lifetime Residential
WaterSense Certified
